产品型号

型号	尺寸	频率范围	标准公差	精度	工作温度	脚位
QESM12	1.2 x 1.0 x 0.3 mm	26 to 96 MHz	±10 to 50 ppm	≤±10 to 50 ppm	-40 to 85 °C	4
QESM10	1.6 x 1.2 x 0.4 mm	24 to 54 MHz	±10 to 30 ppm	≤±10 to 30 ppm	-40 to 85 °C	4
QESM09	2.0 x 1.6 x 0.45 mm	16 to 96 MHz	±10 to 30 ppm	≤±10 to 30 ppm	-40 to 85 °C	4
QESM08	2.5 x 2.0 x 0.65 mm	12 to 54 MHz	±10 to 30 ppm	≤±10 to 30 ppm	-40 to 85 °C	4
QESM07	3.2 x 2.5 x 0.65 mm	10 to 64 MHz	±10 to 30 ppm	≤±10 to 30 ppm	-40 to 85 °C	4
QESM05	5.0 x 3.2 x 0.9 mm	8 to 80 MHz	±10 to 50 ppm	≤±10 to 50 ppm	-40 to 85 °C	4
QESM052	5.0 x 3.2 x 1.4 mm	8 to 80 MHz	±30 to 100 ppm	≤±30 to 100 ppm	-40 to 85 °C	2
QESM04	6.0 x 3.5 x 1.0 mm	10 to 100 MHz	±10 to 50 ppm	≤±10 to 80 ppm	-40 to 85 °C	2
QESM01	7.0 x 5.0 x 1.2 mm	6 to 100 MHz	±10 to 50 ppm	≤±10 to 50 ppm	-40 to 85 °C	4
QESM49	11.4 x 4.5 x 4.0 mm 11.4 x 4.5 x 3.2 mm	3 to 100 MHz	±10 to 50 ppm	≤±10 to 50 ppm	-40 to 85 °C	5
QESM405	13.0 x 5.0 x H mm	3.57 to 130 MHz	±10 to 50 ppm	≤±10 to 50 ppm	-40 to 85 °C	4

型号	尺寸	频率范围	频偏	工作温度	负载电容	脚位
RTF1610	1.6 x 1.0 x 0.5 mm	32.768 kHz	-0.03 ppm/°C2	-40 to 85 °C	6, 7, 9 and 12.5 pF	2
RTF2012	2.0 x 1.2 x 0.5 mm	32.768 kHz	-0.03 ppm/°C2	-40 to 85 °C	6, 9, and 12.5 pF	2
RTF3215	3.2 x 1.5 x 0.5 mm	32.768 kHz	-0.03 ppm/°C2	-40 to 85 °C	6, 7, 9 and 12.5 pF	2
QETF32.768-SMD01	8.0 x 3.8 x 2.5 mm	32.768 kHz	-0.04 ppm/°C2	-40 to 85 °C	12.5±0.2 pF	4
QETF26	Ø2.0 x 6.0 mm	32.768 kHz	-0.042 ppm/°C2	-10 to 60 °C	12.5 pF	2
QETF38	Ø3.0 x 8.0 mm	32.768 kHz	-0.042 ppm/°C2	-10 to 60 °C	12.5 pF	2

型号	尺寸	频率范围	标准公差	精度	工作温度	脚位
QEUM1	7.9 x 3.2 x 8.0 mm	10 to 200 MHz	±10 to 50 ppm	≤±10 to 50 ppm	-40 to 85 °C	2
QEUM5	7.9 x 3.2 x 6.0 mm	10 to 200 MHz	±10 to 50 ppm	≤±10 to 50 ppm	-40 to 85 °C	2
QEHC49H3	11.5 x 5.0 x 3.56 mm	3.2 to 66 MHz	±10 to 50 ppm	≤±10 to 50 ppm	-40 to 85 °C	2
QEHC49U	11.5 x 5.0 x 13.46 mm	1.8432 to 125 MHz	±10 to 50 ppm	≤±10 to 50 ppm	-40 to 85 °C	2
HC-45 UM1	8.15 x 3.3 x H mm	16 to 130 MHz	±10 ppm	≤±4 to 40 ppm	-40 to 85 °C	2
HC-48/U, HC-36/U, HC-6/U	19.4 x 9.1 x 19.7 mm	0.8 to 125 MHz	±10 to 30 ppm	≤±10 to 30 ppm	-40 to 85 °C	2
HC-49/U, HC-43/U, HC-18/U	11 x 4.5 x 13.4 mm	3 to 130 MHz	±10 to 30 ppm	≤±10 to 30 ppm	-40 to 85 °C	2
HC-50/U, HC-25/U, HC-42/U	12 x 4.5 x 13.4 mm	2.9 to 61 MHz	±30 ppm	≤±30 ppm	-40 to 85 °C	2
HC-35/U, RW TO-5	Φ8.23 x H mm	10 to 130 MHz	±10 ppm	≤±4 to 40 ppm	-40 to 85 °C	4
HC-37/U, RW TO-8	Φ21.35 x H mm	3 to 60 MHz	±10 ppm	≤±4 to 40 ppm	-40 to 85 °C	5
HC-40 E7	Φ21.35 x H mm	1 to 10 MHz	±10 ppm	≤±4 to 40 ppm	-40 to 85 °C	4

型号	尺寸	频率范围	标准公差	精度	工作温度	负载电容
RSX1612	1.6 x 1.2 x 0.35 mm	16 to 80 MHz	≤±15 ppm	≤±15 to 50 ppm	-40 to 125 °C	5 to 32 pF
RSX-11	2.0 x 1.6 x 0.5 mm	16 to 80 MHz	≤±15 ppm	≤±15 to 50 ppm	-40 to 125 °C	5 to 32 pF
RSX-10	2.5 x 2.0 x 0.55 mm	12 to 66 MHz	≤±15 ppm	≤±15 to 50 ppm	-40 to 125 °C	5 to 32 pF
RSX-8	3.2 x 2.5 x 0.6 mm	8 to 150 MHz	≤±10 to 50 ppm	≤±15 to 50 ppm	-40 to 125 °C	5 to 32 pF

型号	尺寸	封装	频率范围	工作温度	稳定性	脚位
RHX3500	Ø8.26 x 6.8 mm	T807	14 to 140 MHz	-55 to 125 °C	≤±0.5 ppm/20 years	3
RHX3700	Ø12.95 x 6.8 mm	T1507	3 to 71 MHz	-55 to 180 °C	≤±0.5 ppm/20 years	5
CFPX3750	Ø10.7 x 8.8 mm	T807	14 to 140 MHz	-55 to 180°C	≤±5 ppb/year	3
CFPX3758	Ø15.75 x 6.8 mm	T1507	3 to 50 MHz	-55 to 180°C	≤±5 ppb/year	5
CFPX3000	Ø22 x 11.8 mm	T2111	2 to 50 MHz	-55 to 180°C	≤±5 ppb/year	5

型号	图片	尺寸	封装	频率范围	带宽	工作温度	插入损耗
FTF-4		55×25×15 mm	DIL	3 to 150 MHz	0.001 至 1%	-45 to 90 °C	2 to 8 dB min.

型号	尺寸	中心频率	带宽	损耗	磁极	终止
FTF4827	38.4 x 18.2 x 13.0 mm	10.7 MHz	±25 kHz	4 dB	6	50 Ω // 0 pF
FTF4834	23.5 x 16.9 x 10.7 mm	10.7 MHz	±15 kHz	3.5 dB	8	5600 Ω // -1 pF
FTF4869	7.0 x 5.0 x 1.0 mm	21.4 MHz	±100 kHz	3 dB	4	1900 Ω // 1.6 pF
FTF4870	7.0 x 5.0 x 1.0 mm	21.4 MHz	±15 kHz	3 dB	4	2000 Ω // 0.5 pF
FTF4824	38.4 x 18.2 x 13.0 mm	21.4 MHz	±7.5 kHz	4 dB	6	50 Ω // 0 pF
FTF4874	38.4 x 18.2 x 13.0 mm	21.4 MHz	±7.5 kHz	9 dB	6	50 Ω // 0 pF
FTF4875	38.4 x 18.2 x 13.0 mm	21.4 MHz	±10 kHz	8 dB	6	50 Ω // 0 pF
FTF4876	38.4 x 18.2 x 13.0 mm	21.4 MHz	±25 kHz	9 dB	6	50 Ω // 0 pF
FTF4842	23.0 x 12.2 x 15.1 mm	21.4 MHz	±50 kHz	4.5 dB	8	50 Ω // 0 pF
FTF4853	23.0 x 12.2 x 15.1 mm	21.4 MHz	±100 kHz	4 dB	10	50 Ω // 0 pF
FTF4883	25.1 x 14.1 x 10.0 mm	25 MHz	±3.5 kHz	6 dB	10	3500 Ω // 2.0 pF
FTF4835	7.0 x 5.0 x 1.35 mm	45 MHz	±6 kHz	2.5 dB	4	550 Ω // 3 pF
FTF4863	7.0 x 5.0 x 1.35 mm	70 MHz	±6.25 kHz	6 dB	4	500 Ω // 3pF
FTF4848	25.0 x 12.7 x 4.0 mm	70 MHz	±12.5 kHz	6 dB	2	50 Ω // 0 pF
FTF4820	25.1 x 14.1 x 10.5 mm	70 MHz	±6.25 kHz	6 dB	6	50 Ω // 0 pF
FTF1858	25.0 x 16.0 x 11.0 mm	75 MHz	±7.5 kHz	4 dB	4	50 Ω // 0 pF
FTF4851	7.0 x 5.0 x 1.35 mm	90 MHz	±22 kHz	4 dB	4	760 Ω // 0.6 pF
FTF4879	7.0 x 5.0 x 1.35 mm	90 MHz	±8 kHz	7 dB	4	310 Ω // 3.2 pF
FTF4885	7.0 x 5.0 x 1.35 mm	90 MHz	±3.125 kHz	4 dB	4	500Ω // 1.5 pF
FTF4886	7.0 x 5.0 x 1.35 mm	90 MHz	±7.5 kHz	4 dB	4	500 Ω // 1.5 pF
FTF4913	7.0 x 5.0 x 1.35 mm	90 MHz	±3.125 kHz	4 dB	4	500 Ω // 1.5 pF
FTF4860	40.0 x 21.0 x 11.0 mm	90 MHz	±12.5 kHz	7 dB	8	50 Ω // 0 pF
FTF4862	25.1 x 14.1 x 10.5 mm	90 MHz	±3.75 kHz	5 dB	8	50 Ω // 0 pF
FTF4884	25.1 x 14.1 x 10.0 mm	109.65 MHz	±15 kHz	5 dB	4	50Ω // 0 pF

型号	尺寸	中心频率	带宽	插入损耗	配置	工作温度
TMX FT01	5.0 x 5.0 x 1.5 mm	169 MHz	6.00 MHz	1.5 dB	Single 50Ω / Single 50	-40 to 85 °C
TMX W363	3.8 x 3.8 x 1.5 mm	428 MHz	4.00 MHz	3.0 dB	Single 50Ω / Single 50	-10 to 50 °C
TMX FT06	5.0 x 5.0 x 1.3 mm	433.42 MHz	0.32 MHz	2.0dB	Single 50Ω / Single 50	-40 to 85 °C
TMX HT05	3.0 x 3.0 x 1.25 mm	433.42 MHz	0.60 MHz	2.1 dB	Single 50Ω / Single 50	-20 to 70 °C
TMX U387	3.8 x 3.8 x 1.2 mm	433.42 MHz	0.60 MHz	3.5 dB	Single 50Ω / Single 50	-10 to 60 °C
TMX HT07	3.0 x 3.0 x 1.1 mm	433.6 MHz	0.60 MHz	2.8 dB	Single 50Ω / Single 50	-40 to 85 °C
TMX CT04	3.0 x 3.0 x 1.5 mm	433.92 MHz	1.71 MHz	2.0 dB	Single 50Ω / Single 50	-10 to 60 °C
TMX DT03	3.0 x 3.0 x 1.3 mm	433.92 MHz	1.60 MHz	2.2 dB	Single 50Ω / Single 50	-40 to 85 °C
TMX JT01	5.0 x 5.0 x 1.35 mm	433.92 MHz	2.00 MHz	2.2 dB	Single 50Ω / Single 50	-10 to 65 °C
TMX U386	3.8 x 3.8 x 1.5 mm	433.92 MHz	1.58 MHz	2.8 dB	Single 50Ω / Single 50	-40 to 85 °C
TMX U388	5.0 x 5.0 x 1.3 mm	433.92 MHz	0.32 MHz	2.0 dB	Single 50Ω / Single 50	-40 to 85 °C
TMX DT05	3.8 x 3.8 x 1.25 mm	448 MHz	3.00 MHz	2.0 dB	Single 50Ω / Single 50	-30 to 85 °C
TMX JT07	5.0 x 5.0 x 1.35 mm	480 MHz	36.00 MHz	21.5 dB (TBC?)	Single 50Ω / Single 50	-25 to 85 °C
TMX JT05	3.0 x 3.0 x 1.1 mm	763.5 MHz	17.25 MHz	2.5 dB	Single 50Ω / Single 50	-40 to 85 °C
TMX CT03	3.0 x 3.0 x 1.1 mm	770 MHz	20.00 MHz	2.1 dB	Single 50Ω / Single 50	-20 to 70 °C
TMX JT03	3.0 x 3.0 x 1.1 mm	771 MHz	3.00 MHz	2.5 dB	Single 50Ω / Single 50	-40 to 85 °C
TMX HT02	3.0 x 3.0 x 1.3 mm	800 MHz	20.00 MHz	2.0 dB	Single 50Ω / Single 50	-40 to 85 °C
TMX IT01	3.0 x 3.0 x 1.3 mm	829 MHz	0.40 MHz	2.5 dB	Single 50Ω / Single 50	-40 to 85 °C
TMX W322	3.0 x 3.0 x 1.3 mm	836.5 MHz	25.00 MHz	2.5 dB	Single 50Ω / Single 50	-40 to 85 °C
TMX W357	3.0 x 3.0 x 1.4 mm	860.5 MHz	19.00 MHz	2.2 dB	Single 50Ω / Single 50	-30 to 85 °C
TMX W333	3.0 x 3.0 x 1.5 mm	864 MHz	3.00 MHz	2.5 dB	Single 50Ω / Single 50	-40 to 80 °C
TMX HT08	3.0 x 3.0 x 1.3 mm	866 MHz	2.00 MHz	2.2 dB	Single 50Ω / Single 50	-40 to 85 °C
TMX W340	3.0 x 3.0 x 1.4 mm	866 MHz	12.00 MHz	2.0 dB	Single 50Ω / Single 50	-30 to 75 °C
TMX CT05	3.0 x 3.0 x 1.3 mm	866.5 MHz	7.00 MHz	2.4 dB	Single 50Ω / Single 50	-40 to 125 °C
TMX AT04	3.8 x 3.8 x 1.2 mm	868.3 MHz	0.78 MHz	2.7 dB	Single 50Ω / Single 50	'-40 to 85 °C
TMX U394	5.0 x 5.0 x 1.35 mm	868.3 MHz	1.20 MHz	4.0 dB	Single 50Ω / Single 50	-40 to 85 °C
TMX GT02	3.0 x 3.0 x 1.3 mm	868.6 MHz	2.00 MHz	2.6 dB	Single 50Ω / Single 50	-40 to 85 °C
TMX IT03	1.4 x 1.1 x 0.7 mm	869 MHz	2.00 MHz	2.9 dB	Single 50Ω / Single 50	-40 to 85 °C
TMX W330	3.8 x 3.8 x 1.5 mm	869 MHz	2.00 MHz	2.5 dB	Single 50Ω / Single 50	-40 to 85 °C
TMX W331	3.0 x 3.0 x 1.25 mm	869 MHz	2.00 MHz	2.5 dB	Single 50Ω / Single 50	-40 to 85 °C
TMX W341	5.0 x 5.0 x 1.5 mm	869.6 MHz	0.98 MHz	3.0 dB	Single 50Ω / Single 50	-40 to 85 °C
TMX W319	3.0 x 3.0 x 1.3 mm	902.5 MHz	25.00 MHz	2.9 dB	Single 50Ω / Single 50	-30 to 85 °C
TMX AT13	3.8 x 3.8 x 1.7 mm	915 MHz	26.00 MHz	2.5 dB	Single 50Ω / Single 50	-30 to 85 °C
TMX AT14	3.0 x 3.0 x 1.3 mm	915 MHz	26.00 MHz	2.5 dB	Single 50Ω / Single 50	-30 to 85 °C
TMX IT02	3.0 x 3.0 x 1.3 mm	915 MHz	26.00 MHz	2.3 dB	Single 50Ω / Single 100Ω	-40 to 85 °C
TMX LT02	1.4 x 1.1 x 0.7 mm	915 MHz	26.00 MHz	2.7 dB	Single 50Ω / Single 50	-40 to 85 °C
TMX U392	3.0 x 3.0 x 1.3 mm	915 MHz	26.00 MHz	2.5 dB	Single 50Ω / Single 50	0 to 70 °C
TMX U393	3.8 x 3.8 x 1.5 mm	915 MHz	26.00 MHz	2.5 dB	Single 50Ω / Single 50	-0 to 70 °C
TMX DT01	3.0 x 3.0 x 1.3 mm	916.45 MHz	4.00 MHz	2.7 dB	Single 50Ω / Single 50Ω	-30 to 85 °C
TMX W329	3.0 x 3.0 x 1.5 mm	942.5 MH	35.00 MHz	2.8 dB	Single 50Ω / Single 50	-30 to 85 °C
TMX AT15	3.8 x 3.8 x 1.5 mm	1030 MH	30.00 MHz	2.3 dB	Single 50Ω / Single 50	-30 to 85 °C
TMX AT03	3.8 x 3.8 x 1.2 mm	1090 MH	8.00 MHz	3.9 dB	Single 50Ω / Single 50	'-40 to 85 °C
TMX IT07	3.0 x 3.0 x 1.3 mm	1220 MH	40.00 MHz	2.5 dB	Single 50Ω / Single 50Ω	-40 to 85 °C
TMX W403	3.8 x 3.8 x 1.2 mm	1220 MH	8.00 MHz	3.7 dB	Balanced 50Ω / Balanced 200Ω	-40 to 85 °C
TMX JT04	3.0 x 3.0 x 1.1 mm	1395 MH	20.00 MHz	2.3 dB	Single 50Ω / Single 50	-40 to 85 °C
TMX FT02	1.4 x 1.1 x 0.7 mm	1575.42 MHz	2.00 MHz	0.9 dB	Single 50Ω / Single 50	-40 to 85 °C
TMX W312	2.5 x 2.0 x 0.75 mm	1575.42 MHz	2.40 MHz	1.5	Single 50Ω / Single 50Ω	-40 to 85 °C
TMX W347	3.0 x 3.0 x 1.4 mm	1575.42 MHz	2.00 MHz	2.6 dB	Single 50Ω / Single 50	-40 to 85 °C
TMX MT01	1.1 x 0.9 x 0.65 mm	1580 MHz	46.8 MHz	1.8 dB	Single 50Ω / Single 50Ω	-30 to 85 °C
TMX IT04	1.4 x 1.1 x 0.7 mm	1580 MHz	2.00 MHz	1.3 dB	Single 50Ω / Single 50	-40 to 85 °C
TMX W311	2.5 x 2.0 x 1.0 mm	1960 MHz	60.00 MHz	2.7	Single 50Ω / Balanced 200Ω	-40 to 85 °C
TMX W365	2.5 x 2.0 x 1.0 mm	2140 MHz	60.00 MHz	2.4	Single 50Ω / Balanced 200Ω	-40 to 85 °C
TMX W353	3.0 x 3.0 x 1.4 mm	2441.8 MHz	83.50 MHz	2.1 dB	Single 50Ω / Single 50	-40 to 85 °C

型号	尺寸	中心频率	带宽	插入损耗	阻带	工作温度	封装
LTS455BW	11.0 x 7.0 x 7.5 mm	455 kHz	±15.0 KHz	6.0 dB	45 dB min	-20 to 80 °C	THT
LTUPC455GB	7.5 x 5.0 x 8.4 mm	455 kHz	±4.5 KHz	6.0 dB	25 dB min	-20 to 80 °C	SMD
LTUCG450B	6.5 x 6.0 x 4.0 mm	450 kHz	±15.0 KHz	4.0 dB	25 dB min	-20 to 80 °C	SMD
LTUCG450G	6.5 x 6.0 x 4.0 mm	450 kHz	±4.5 KHz	6.0 dB	25 dB min	-20 to 80 °C	SMD

型号	尺寸	频率范围	精度	工作温度	相位抖动	电压
RXO2016C	2.0 x 1.6 x 0.85 mm	1.5 to 54 MHz	≤±25 to 50 ppm	-40 to 125 °C	1 ps; 12 kHz to 20 MHz	1.8; 2.5; 3.3 V
RXO2520C	2.5 x 2.0 x 0.8 mm	0.5 to 133 MHz	≤±25 to 50 ppm	-40 to 125 °C	1 ps; 12 kHz to 20 MHz	1.8; 2.5; 3.3 V
RXO3225C	3.2 x 2.5 x 0.9 mm	0.5 to 156.25 MHz	≤±25 to 50 ppm	-40 to 125 °C	1 ps; 12 kHz to 20 MHz	1.8; 2.5; 3.3 V
RXO7050C	7.0 x 5.0 x 1.4 mm	0.5 to 160 MHz	≤±25 to 50 ppm	-40 to 125 °C	1 ps; 12 kHz to 20 MHz	1.8; 2.5; 3.3 V

型号	尺寸	频率范围	精度	工作温度	相位抖动	电压
RXO2016M	2.0 x 1.6 x 0.75 mm	31.5 to 160 MHz	≤±25 to 100 ppm	-40 to 105 °C	0.1~1 ps; 12 kHz to 20 MHz	1.8; 2.5; 3.3 V
RXO2520M	2.5 x 2.0 x 1.1 mm	13.5 to 200 MHz	≤±25 to 50 ppm	-40 to 125 °C	0.1~0.3 ps; 12 kHz to 20 MHz	1.8; 2.5; 3.3 V
RXO3225M	3.2 x 2.5 x 0.95 mm	13.5 to 200 MHz	≤±25 to 100 ppm	-40 to 125 °C	0.1~1 ps; 12 kHz to 20 MHz	1.8; 2.5; 3.3 V
RXO5032M	5.0 x 3.2 x 1.2 mm	60 to 312.5 MHz	≤±15 to 50 ppm	-40 to 105 °C	0.1 ps; 12 kHz to 20 MHz	2.5 V
RXO7050M	7.0 x 5.0 x 1.4 mm	13.5 to 800 MHz	≤±25 to 100 ppm	-40 to 85 °C	0.1~1 ps; 12 kHz to 20 MHz	1.8, 2.5, 3.3 V

型号	图片	尺寸	频率范围	精度	工作温度	相位抖动	电压
RXO2520P		2.5 x 2.0 x 0.8 mm	8 to 1500 MHz	≤±25 to 50 ppm	-40 to 85 °C	0.5 ps; 12 kHz to 20 MHz	2.5; 3.3 V
RXO2520R		2.5 x 2.0 x 0.8 mm	8 to 1500 MHz	≤±25 to 50 ppm	-40 to 85 °C	1 ps; 12 kHz to 20 MHz	2.5; 3.3 V

型号	尺寸	频率范围	精度	工作温度	长期稳定性	电压
RXO5032AD	5.0 x 3.2 x 1.2 mm	5 to 1500 MHz	≤±30 ppm	-40 to 85 °C -55 to 125 °C	≤±15 ppm/10 years	2.5; 3.3 V
QEN55	20.7 x 13.1 x 5.1 mm	1.5 to 100 MHz	≤±20 ppm	-40 to 85 °C -55 to 125 °C	≤±5 ppm/year @45 °C	3.3; 5 V
QEN49	20.7 x 13.1 x 5.1 mm	1.5 to 100 MHz	≤±20 ppm	-40 to 85 °C -55 to 125 °C	≤±5 ppm/year @45 °C	3.3; 5 V

型号	尺寸	频率范围	精度	工作温度	长期稳定性	电压
ESCC3503001	16 x 16 x 3.8 mm	4 to 100 MHz	≤±30 ppm (4 – 80 MHz) ≤±40 ppm (80 – 100 MHz)	-55 to 110 °C	≤±15 ppm/18 years	3.3 V
RK115JL2	14 x 9 x 3.8 mm	2 to 100 MHz	≤±30 ppm	-40 to 110 °C	≤±15 ppm/18 years	3.3 V
RK115FP2	16 x 16 x 3.8 mm	2 to 100 MHz	≤±30 ppm	-40 to 110 °C	≤±15 ppm/18 years	3.3 V
RK115FP4	13 x 10 x 3 mm	2 to 100 MHz	≤±30 ppm	-40 to 110 °C	≤±15 ppm/18 years	3.3 V
RK115FP1	15 x 20 x 3.6 mm	2 to 100 MHz	≤±30 ppm	-40 to 110 °C	≤±15 ppm/18 years	3.3 V
RK115FP3	16 x 16 x 3.6 mm	2 to 100 MHz	≤±30 ppm	-40 to 110 °C	≤±15 ppm/18 years	3.3 V

型号	图片	尺寸	频率范围	精度	工作温度	长期稳定性	电压
RXO2213S		22 x 13 x 4.8 mm	0.256 to 52.5 MHz	≤±50 ppm	-55 to 125 °C	≤±3 ppm/year	3.3; 5 V

型号	图片	尺寸	频率范围	精度	工作温度	长期稳定性	电压
RK105		5.0 x 3.2 x 1.2 mm	8 to 200 MHz	≤±30 ppm ≤±50 ppm	-40 to 85 °C -55 to 125 °C	≤±15 ppm/10 years	2.5; 3.3 V

型号	尺寸	封装	频率范围	精度	工作温度	输出
QEN09	2.0 x 1.6 x 0.8 mm	SMD	0.25 to 125 MHz	≤±25 to 100 ppm	-55 to 125°C	HCMOS
QEN08	2.5 x 2.0 x 0.9 mm	SMD	1 to 54 MHz	≤±25 to 100 ppm	-40 to 85 °C	HCMOS
QEN07	3.2 x 2.5 x 1.2 mm	SMD	0.25 to 125 MHz	≤±25 to 100 ppm	-55 to 125 °C	HCMOS
QEN05	5.0 x 3.2x 1.3 mm	SMD	0.25 to 156.25 MHz	≤±25 to 100 ppm	-55 to 125 °C	HCMOS
QEN101	7.0 x 5.0 x 1.4 mm	SMD	1 to 133 MHz	≤±25 to 100 ppm	-40 to 85 °C	HCMOS TTL Load
QEN62	14.0 x 9.8 x 4.7 mm	JL SMD	1 to 125 MHz	≤±25 to 100 ppm	-40 to 85 °C	HCMOS TTL Load
QEN4	12.6 x 12.6 x 5.6 mm	DIL	0.5 to 150 MHz	≤±15 to 100 ppm	-40 to 85 °C	HCMOS TTL Load
QEN14	20.7 x 13.1 x 5.08 mm 20.7 x 13.1 x 7.5 mm	DIL	0.4096 to 150 MHz	≤±15 to 100 ppm	-40 to 85 °C	HCMOS TTL Load

型号	图片	尺寸	频率范围	频率漂移	工作温度	相位噪声	调谐范围
RVC1616S		16 x 16 x 4.3 mm	950 to 1450 MHz	60 MHz	-10 to 55 °C	Typ. P/N -99 dBc/Hz @10 kHz -122 dBc/Hz @100 kHz	45 to 75 MHz/V

型号	图片	尺寸	频率范围	频率漂移	工作温度	相位噪声	谐调范围
RVC1414D		Ø14 x 5 mm	980 to 1215 MHz	60 MHz	-40 to 100 °C	Max. P/N -90 dBc/Hz @50 kHz	25 MHz/V

型号	尺寸	频率范围	精度	工作温度	相位噪声	绝对牵引范围
RVX1490U	14 x 9 x 2.8 mm	76.8 to 245.76 MHz	≤±20 ppm	-40 to 95 °C	Typ. value @153.6 MHz -109 dBc/Hz @100 Hz -154 dBc/Hz @10 kHz -174 dBc/Hz @1 MHz	±5 ppm min.
RVX5032M	5.0 x 3.2 x 1.2 mm	60 to 250 MHz	≤±15 to 50 ppm	-40 to 105 °C	Typ. P/N @122.88 MHz -103 dBc/Hz @100 Hz -148 dBc/Hz @10 kHz -155 dBc/Hz @1 MHz	±50 to 200 ppm
RVX7050M	7.0 x 5.0 x 1.6 mm	60 to 250 MHz	≤±15 to 50 ppm	-40 to 105 °C	Typ. P/N @122.88 MHz -103 dBc/Hz @100 Hz -148 dBc/Hz @10 kHz -155 dBc/Hz @1 MHz	±50 to 200 ppm
RVX2520P	2.5 x 2.0 x 0.8 mm	8 to 1500 MHz	≤±25 to 50 ppm	-40 to 85 °C	Available on request	±65 to 200 ppm
RVX2520R	2.5 x 2.0 x 0.8 mm	8 to 1500 MHz	≤±25 to 50 ppm	-40 to 85 °C	Available on request	±65 to 200 ppm

型号	图片	尺寸	频率范围	精度	工作温度	长期稳定性	调谐范围
RSV2522		25 x 22 x 5 mm	0.5 to 2 GHz	≤±100 ppm	-40 to 85 °C	≤±5 ppm/year ≤±10 ppm/ 10 years	>500 ppm

型号	图片	尺寸	频率范围	精度	工作温度	长期稳定性	绝对牵引范围
TE200		20 x 20 x 13 mm	10 to 40 MHz	≤±10 to 15 ppm	0 to 70°C -20 to 70°C	≤±5 ppm/15 years	±40 to 70 ppm

型号	图片	尺寸	频率范围	精度	工作温度	长期稳定性	绝对牵引范围
RVX2213S		22 x 13 x 4.8 mm	0.032 to 40 MHz	≤±50 ppm	-30 to 60°C	≤±5 ppm/year (afterwards, ±2 ppm/year)	±250 ppm min.
RVX3520S		35 x 20 x 10 mm	0.032 to 94 MHz	≤±15 ppm	-30 to 60°C	≤±1 ppm/year	±40 ppm min.

型号


尺寸

频率范围

精度

工作温度

长期稳定性

绝对牵引范围

RVX2213S

22 x 13 x 4.8 mm

0.032 to 40 MHz

≤±50 ppm

-30 to 60°C

≤±5 ppm/year

(afterwards, ±2 ppm/year)

±250 ppm min.

RVX3520S

35 x 20 x 10 mm

0.032 to 94 MHz

≤±15 ppm

-30 to 60°C

≤±1 ppm/year

±40 ppm min.

型号	图片	尺寸	频率范围	精度	工作温度	长期稳定性	绝对牵引范围
RK205		5 x 3.2 x 1.2 mm	8 to 1500 MHz	≤±30 ppm ≤±50 ppm	-40 to 85°C -55 to 125°C	≤±15 ppm/10 years	±50 ppm min.
RK200NS		25 x 25 x 13 mm	10 to 120 MHz	≤±13 ppm	-20 to 70°C	≤±5 ppm/1 year ≤±20 ppm/12 years	±20 ppm typ.

型号	尺寸	封装	频率范围	精度	工作温度	绝对牵引范围
QEV07	3.2 x 2.5 x 0.7 mm	SMD	1 to 170 MHz	≤±25 to 100 ppm	-40 to 85 °C	±3 ppm/year
QEV05	5.0 x 3.2x 1.3 mm	SMD	1 to 170 MHz	≤±25 to 100 ppm	-40 to 85 °C	±3 ppm/year
QEV101	7.0 x 5.0 x 1.4 mm	SMD	1 to 170 MHz	≤±25 to 100 ppm	-40 to 85 °C	±3 ppm/year
QEV4	12.6 x 12.6 x 5.6 mm	DIL	1 to 160 MHz	≤±15 to 100 ppm	-40 to 85 °C	±5 ppm/year
QEV14	20.7 x 13.1 x 5.08 mm 20.7 x 13.1 x 7.5 mm	DIL	1 to 160 MHz	≤±15 to 100 ppm	-40 to 85 °C	±5 ppm/year

型号	图片	尺寸	频率范围	精度	工作温度	输出波形	相位噪声
RST2016AL		2.0 x 1.6 x 0.7 mm	13 to 52 MHz	≤±0.5 ppm	-40 to 85 °C	Clipped Sinewave	Typ. @26 MHz -93 dBc/Hz @10 Hz -135 dBc/Hz @1 kHz -149 dBc/Hz @100 kHz

型号	尺寸	频率范围	精度	工作温度	输出波形	相位噪声
RST2016A	2.0 x 1.6 x 0.7 mm	13 to 52 MHz	≤±0.5 to 1.5 ppm	-40 to 85 °C	Clipped Sinewave	Typ. P/N @26 MHz -93 dBc/Hz @10 Hz -140 dBc/Hz @1 kHz -156 dBc/Hz @100 kHz
RST2520A	2.5 x 2.0 x 0.8 mm	13 to 52 MHz	≤±0.5 to 1.5 ppm	-40 to 85 °C	Clipped Sinewave	Typ. P/N @26 MHz -93 dBc/Hz @10 Hz -140 dBc/Hz @1 kHz -156 dBc/Hz @100 kHz
RST3225A	3.2 x 2.5 x 0.9 mm	13 to 52 MHz	≤±0.5 to 1.5 ppm	-40 to 85 °C	Clipped Sinewave	Typ. P/N @26 MHz -90 dBc/Hz @10 Hz -138 dBc/Hz @1 kHz -156 dBc/Hz @100 kHz

型号	尺寸	频率范围	精度	工作温度	输出波形	相位噪声
RST2016H	2.0 x 1.6 x 0.7 mm	13 to 52 MHz	≤±0.5 to 1.5 ppm	-40 to 105 °C	Clipped Sinewave	Typ. P/N @26 MHz -92 dBc/Hz @10 Hz -136 dBc/Hz @1 kHz -153 dBc/Hz @100 kHz
RST2520H	2.5 x 2.0 x 0.8 mm	10 to 52 MHz	≤±0.5 to 1.5 ppm	-40 to 105 °C	Clipped Sinewave	Typ. P/N @26 MHz -92 dBc/Hz @10 Hz -136 dBc/Hz @1 kHz -153 dBc/Hz @100 kHz
RST3225H	3.2 x 2.5 x 0.9 mm	10 to 52 MHz	≤±0.5 to 1.5 ppm	-40 to 105 °C	Clipped Sinewave	Typ. P/N @26 MHz -92 dBc/Hz @10 Hz -136 dBc/Hz @1 kHz -153 dBc/Hz @100 kHz
RST2016HC	2.0 x 1.6 x 0.7 mm	13 to 52 MHz	≤±2.5 to 5 ppm	-40 to 105 °C	CMOS	Typ. P/N @38.4 MHz -91 dBc/Hz @10 Hz -139 dBc/Hz @1 kHz -155 dBc/Hz @10 kHz
RST2520HC	2.5 x 2.0 x 0.8 mm	10 to 52 MHz	≤±2.5 to 5 ppm	-40 to 105 °C	CMOS	Typ. P/N @38.4 MHz -91 dBc/Hz @10 Hz -139 dBc/Hz @1 kHz -155 dBc/Hz @10 kHz
RST3225HC	3.2 x 2.5 x 0.9 mm	10 to 52 MHz	≤±2.5 to 5 ppm	-40 to 105 °C	CMOS	Typ. P/N @38.4 MHz -91 dBc/Hz @10 Hz -139 dBc/Hz @1 kHz -155 dBc/Hz @10 kHz

型号	尺寸	频率范围	精度	工作温度	长期稳定性	相位噪声
RTN7050A	7.0 x 5.0 x 1.5 mm	10 to 160 MHz	≤±100 to 280 ppb	-40 to 105°C	≤±10 ppb/day ≤±1 ppm/year ≤±4.6 ppm/20 years	Typ. P/N @38.88 MHz -69 dBc/Hz @1 Hz -125 dBc/Hz @100 Hz -170 dBc/Hz @1 MHz
RTN5032A	5.0 x 3.2 x 1.75 mm	10 to 160 MHz	≤±100 to 280 ppb	-40 to 105°C	≤±10 ppb/day ±1 ppm/year ≤±4.6 ppm/20 years	Typ. P/N @38.88 MHz -69 dBc/Hz @1 Hz -125 dBc/Hz @100 Hz -170 dBc/Hz @1 MHz
RTN5032D	5.0 x 3.2 x 1.2 mm	10 to 160 MHz	≤±100 to 280 ppb	-55 to 105°C	≤±10 ppb/day ≤±1 ppm/year ≤±4.6 ppm/20 years	Typ. P/N @38.88 MHz -69 dBc/Hz @1 Hz -125 dBc/Hz @100 Hz -170 dBc/Hz @1 MHz
RHT1490A	14.4 x 9.2 x 4.7 mm	50 to 204.8 MHz	≤±0.25 to 0.5 ppm	-40 to 85 °C	≤±1.5 ppm/year ≤±2 ppm/3 years ≤±4 ppm/10 years	Typ. P/N @98.304 MHz -82 dBc/Hz @10 Hz -132 dBc/Hz @1 kHz -149 dBc/Hz @1 MHz
RHT1490J	14.4 x 9.2 x 4.7 mm	50 to 200 MHz	≤±0.28 to 0.5 ppm	-40 to 85 °C	≤±10 ppb/day ≤±3 ppm/20 years	Typ. P/N @98.304 MHz -82 dBc/Hz @10 Hz -132 dBc/Hz @1 kHz -149 dBc/Hz @1 MHz
RPT5032GX	5.0 x 3.2 x 2.0 mm	10 to 50 MHz	≤±0.5 to 1 ppm	-55 to 105°C	≤±1ppm/year ≤±3ppm/10 years	Typ. P/N @50 MHz -83 dBc/Hz @10 Hz -132 dBc/Hz @1 kHz -144 dBc/Hz @100kHz -152 dBc/Hz @10MHz
RNT7050A	7.0 x 5.0 x 1.5 mm	10 to 50 MHz	≤±50 to 100 ppb ≤±100 to 200 ppb	-40 to 95 °C -40 to 105 °C	≤±50 ppb/day ≤±1.5 ppm/10 years	Typ. P/N @19.2 MHz -103 dBc/Hz @10 Hz -148 dBc/Hz @1 kHz -160 dBc/Hz @1 MHz
RNT7050AL	7.0 x 5.0 x 2.0 mm	10 to 50 MHz	≤±50 to 100 ppb ≤±100 to 200 ppb	-40 to 95 °C -40 to 105 °C	≤±50 ppb/day ≤±1.5 ppm/10 years	Typ. P/N @19.2 MHz -103 dBc/Hz @10 Hz -148 dBc/Hz @1 kHz -160 dBc/Hz @1 MHz
RPT7050A	7.0 x 5.0 x 1.5 mm	1.25 to 52 MHz	≤±0.1 to 0.5 ppm	-55 to 105 °C	≤±1 – ±2 ppm/year ≤±3 – ±4 ppm/10 years	Typ. P/N @40 MHz -94 dBc/Hz @10 Hz -141 dBc/Hz @1 kHz -153 dBc/Hz @1 MHz
RPT5032A	5.0 x 3.2 x 1.75 mm	1.25 to 52 MHz	≤±0.1 to 0.5 ppm	-55 to 105 °C	≤±1 – ±2 ppm/year ≤±3 – ±4 ppm/10 years	Typ. P/N @40 MHz -87 dBc/Hz @10 Hz -137 dBc/Hz @1 kHz -154 dBc/Hz @1 MHz
RPT7050J	7.0 x 5.0 x 1.5 mm	10 to 40 MHz	≤±100 to 280 ppb	-55 to 105 °C	≤±20 ppb/day ≤±200 ppb/month ≤±1 ppm/year ≤±3 ppm/10 years	Typ. P/N @32 MHz -100 dBc/Hz @10 Hz -148 dBc/Hz @1 kHz -159 dBc/Hz @1 MHz
RPT5032J	5.0 x 3.2 x 1.75 mm	10 to 40 MHz	≤±100 to 280 ppb	-55 to 105 °C	≤±20 ppb/day ≤±200 ppb/month ≤±1 ppm/year ≤±3 ppm/10 years	Typ. P/N @32 MHz -100 dBc/Hz @10 Hz -148 dBc/Hz @1 kHz -159 dBc/Hz @1 MHz
RPT7050P	7.0 x 5.0 x 1.5 mm	19.2 to 40 MHz	≤±100 to 500 ppb	-55 to 105 °C	≤±20 ppb/day ≤±200 ppb/month ≤±1 ppm/year ≤±3 ppm/10 years	Typ. P/N @26 MHz -100 dBc/Hz @10 Hz -142 dBc/Hz @1 kHz -156 dBc/Hz @1 MHz
RPT5032P	5.0 x 3.2 x 1.75 mm	19.2 to 40 MHz	≤±100 to 500 ppb	-55 to 105 °C	≤±20 ppb/day ≤±200 ppb/month ≤±1 ppm/year ≤±3 ppm/10 years	Typ. P/N @26 MHz -100 dBc/Hz @10 Hz -142 dBc/Hz @1 kHz -156 dBc/Hz @1 MHz
RPT5032N	5.0 x 3.2 x 1.3 mm	12.8 to 26 MHz	≤±0.2 to 1 ppm	-55 to 105 °C	≤±20 ppb/day ≤±200 ppb/month ≤±1 ppm/year ±2 ppm/3 years	Typ. P/N @19.2 MHz -97 dBc/Hz @10 Hz -143 dBc/Hz @1 kHz -159 dBc/Hz @1 MHz
CFPT9300	5 x 3.2 x 1.3 mm	1.25 to 52 MHz	≤±0.2 to 1.5 ppm	-40 to 105 °C	≤±1 – 2 ppm/year ≤±3 – 5 ppm/10 years	Typ. P/N @14.4 MHz -95 dBc/Hz @10 Hz -135 dBc/Hz @1 kHz -145 dBc/Hz @100 kHz
CFPT9000	7.0 x 5.0 x 1.8 mm 7.0 x 5.0 x 1.6 mm	10 to 40 MHz	≤±0.2 to 1.5 ppm	-40 to 105 °C	≤±1 – 2 ppm/year ≤±3 – 5 ppm/10 years	Typ. P/N @13 MHz -95 dBc/Hz @10 Hz -135 dBc/Hz @1 kHz -145 dBc/Hz @100 kHz

型号	图片	尺寸	频率范围	精度	工作温度	长期稳定性	相位噪声
RPT1490LN		14.5 x 9.5 x 6.0 mm	10 to 50 MHz	≤±0.25 to 0.3 ppm	-40 to 95 °C	≤±1ppm/year ≤±3ppm/15 years	Typ. P/N @38.4 MHz -90 dBc/Hz @10 Hz -153 dBc/Hz @1 kHz -175 dBc/Hz @1 MHz

型号	图片	尺寸	频率范围	精度	工作温度	长期稳定性	应用
RFPT100		7.0 x 5.0 x 1.8 mm	10 to 20 MHz	≤±0.2 ppm	-40 to 55 °C	≤±1 ppm/year ≤±3 ppm/10 years	COSPAS-SARSAT compliant
RPT7050B		7.0 x .0 x 1.5 mm	10 to 20 MHz	≤±0.2 ppm	-55 to 70 °C	≤±1 ppm/year ≤±1.5 ppm/10 years	COSPAS-SARSAT compliant

型号	尺寸	频率范围	精度	工作温度	长期稳定性	灵敏度
RPT7050D	7.0 x 5.0 x 1.5 mm	10 to 52 MHz	≤±0.2 to 0.5 ppm	-55 to 105 °C	≤±1 to 2 ppm/year ≤±3 to 5 ppm / 10 years	0.2 ppb/g typ.
RTN7050A	7.0 x 5.0 x 1.5 mm	10 to 160 MHz	≤±100 to 280 ppb	-40 to 105°C	≤±10 ppb/day ≤±1 ppm/year ≤±4.6 ppm/20 years	0.2 ppb/g
RTN5032A	5.0 x 3.2 x 1.75 mm	10 to 160 MHz	≤±100 to 280 ppb	-40 to 105°C	≤±10 ppb/day ±1 ppm/year ≤±4.6 ppm/20 years	0.2 ppb/g
RTN5032D	5.0 x 3.2 x 1.2 mm	10 to 160 MHz	≤±100 to 280 ppb	-55 to 105°C	≤±10 ppb/day ≤±1 ppm/year ≤±4.6 ppm/20 years	0.2 ppb/g
RPT7050LG	7.0 x 5.0 x 1.5 mm	10 to 52 MHz	≤±0.2 to 0.5 ppm	-55 to 105 °C	≤±1 ppm/year	0.1 ppb/g typ.
RPT7050GP	7.0 x 5.0 x 1.5 mm	10 to 52 MHz	≤±0.2 to 0.5 ppm	-55 to 105 °C	≤±2 ppm/year	0.2 ppb/g typ.

型号	图片	尺寸	频率范围	精度	工作温度	长期稳定性	相位噪声
RTH7050EA		7.5 x 5.5 x 3.3 mm	10 to 50 MHz	≤±5 ppb	-40 to 95 °C	±0.5 ppb/day ≤±4.6 ppm/20 years	Typ. P/N @10 MHz -114 dBc/Hz @100 Hz -160 dBc/Hz @10 kHz -160 dBc/Hz @1 MHz
RTH7050PA		7.5 x 5.5 x 3.3 mm	10 to 50 MHz	≤±20 ppb	-40 to 105 °C	≤±0.3 ppm/year ≤±3.0 ppm/10 years ≤±4.6 ppm/20 years	Typ. P/N @19.2 MHz -137 dBc/Hz @100 Hz -158 dBc/Hz @10 kHz -158 dBc/Hz @1 MHz

型号	图片	尺寸	频率范围	精度	工作温度	长期稳定性	相位噪声
RK300		20 x 20 x13 mm	10 to 100 MHz	≤±0.5 ppm ≤±1 ppm ≤±5 ppm	0 to 50 °C -20 to 70 °C -40 to 85 °C	≤±5 ppm/15 years	Max. P/N @100 MHz -105 dBc/Hz @100 Hz -130 dBc/Hz @1 kHz -145 dBc/Hz @10 kHz

型号	图片	尺寸	频率范围	精度	工作温度	长期稳定性	相位噪声
RTX3520S		35 x 20 x10 mm 35 x 20 x15 mm	5.5 to 375 MHz	≤±1 ppm ≤±2 ppm	-15 to 60 °C -30 to 60 °C	≤±1 ppm/year	Typ. P/N @155 MHz -110 dBc/Hz @100 Hz -130 dBc/Hz @1 kHz -145 dBc/Hz @10 kHz
RTX3825S		38 x 25 x 7 mm	5.5 to 375 MHz	≤±1 ppm ≤±2 ppm	-15 to 60 °C -30 to 60 °C	≤±1 ppm/year	Typ. P/N @155 MHz -110 dBc/Hz @100 Hz -130 dBc/Hz @1 kHz -145 dBc/Hz @10 kHz

型号	尺寸	频率范围	精度	工作温度	长期稳定性	相位噪声
ROM1490X	14.2 x 9.2 x 6.5 mm	10 to 50 MHz	±1.5 ppb	-40 to 95 °C	±0.2 ppb/day ≤±0.3 ppm/year ≤±2.5 ppm/20 years	Typ. P/N @10 MHz -143 dBc/Hz @100 Hz -160 dBc/Hz @10 kHz -160 dBc/Hz @1 MHz
ROM1490E	14.2 x 9.2 x 6.5 mm	10 to 50 MHz	≤±5 ppb	-40 to 85 °C	≤±0.3 ppm/year ≤±2.5 ppm/20 years	Typ. P/N @20 MHz -135 dBc/Hz @100 Hz -158 dBc/Hz @10 kHz -160 dBc/Hz @1 MHz
ROM1490EA	14.3 x 9.1 x 5.9 mm	10 to 50 MHz	≤±10 ppb	-40 to 95 °C	≤±0.3 ppm/year ≤±2.5 ppm/20 years	Typ. P/N @20 MHz -135 dBc/Hz @100 Hz -158 dBc/Hz @10 kHz -160 dBc/Hz @1 MHz
ROM9070EA	9.7 x 7.5 x 3.9 mm	10 to 50 MHz	≤±10 to 20 ppb	-40 to 95 °C	≤±0.3 ppm/year ≤±2.5 ppm/20 years	Typ. P/N @19.2 MHz -137 dBc/Hz @100 Hz -158 dBc/Hz @10 kHz -158 dBc/Hz @1 MHz
ROM1490PS	14.2 x 9.2 x 6.5 mm	10 to 50 MHz	≤±10 ppb	-40 to 85 °C	≤±0.3 ppm/year ≤±1.5 ppm/10 years	Typ. P/N @19.2 MHz -138 dBc/Hz @100 Hz -159 dBc/Hz @10 kHz -160 dBc/Hz @1 MHz
ROM1490PA	14.3 x 9.1 x 5.9 mm	10 to 50 MHz	≤±10 ppb	-40 to 95 °C	≤±0.3 ppm/year ≤±1.5 ppm/10 years90	Typ. P/N @19.2 MHz -138 dBc/Hz @100 Hz -159 dBc/Hz @10 kHz -161 dBc/Hz @1 MHz
ROM9070PA	9.7 x 7.5 x 3.9 mm	10 to 50 MHz	≤±10 to 20 ppb	-40 to 95 °C	≤±0.3 ppm/year ≤±1.5 ppm/10 years	Typ. P/N @19.2 MHz -137 dBc/Hz @100 Hz -158 dBc/Hz @10 kHz -158 dBc/Hz @1 MHz
ROM7050PA	7.5 x 5.5 x 3.3 mm	10 to 50 MHz	≤±20 ppb	-40 to 105 °C	≤±0.3 ppm/year ≤±1.5 ppm/10 years ≤±4.6 ppm/20 years	Typ. P/N @19.2 MHz -137 dBc/Hz @100 Hz -158 dBc/Hz @10 kHz -158 dBc/Hz @1 MHz
RFPO55	14.6 x 9.7 x 6.2 mm	10 to 26 MHz	≤±10 ppb	-40 to 85 °C	≤±3 ppm/year ≤±5 ppm/10 years	Typ. P/N @12.8 MHz -123 dBc/Hz @100 Hz -152 dBc/Hz @10 kHz -154 dBc/Hz @1 MHz
RFPO50	14.6 x 9.7 x 6.2 mm	10 to 40 MHz	≤±20 ppb	-40 to 85 °C	≤±3 ppm/year ≤±5 ppm/10 years	Typ. P/N @12.8 MHz -123 dBc/Hz @100 Hz -152 dBc/Hz @10 kHz -154 dBc/Hz @1 MHz
RFPO45	9.7 x 7.5 x 4.1 mm	10 to 26 MHz	≤±10 to 50 ppb	-40 to 85 °C	≤±3 ppm/year ≤±5 ppm/10 years	Typ. P/N @12.8 MHz -123 dBc/Hz @100 Hz -152 dBc/Hz @10 kHz -154 dBc/Hz @1 MHz
RFPO40	9.7 x 7.5 x 4.1 mm	5 to 50 MHz	≤±10 to 100 ppb	-40 to 85 °C	≤±5 ppm/15 years	Typ. P/N @12.8 MHz -123 dBc/Hz @100 Hz -152 dBc/Hz @10 kHz -154 dBc/Hz @1 MHz

型号	尺寸	频率范围	精度	工作温度	长期稳定性	24小时滞留
ROX5242T1	52 x 42 x 14 mm 52 x 42 x 19 mm	5 to 12.8 MHz	≤±0.1 ppb	-20 to 70 °C	≤±0.02 ppb/day ≤±3 ppb/year ≤±20 ppb/20 years	<1 µs
ROX2522S2	25.4 x 22.0 x 12.1 mm	10 to 20 MHz	≤±0.5 ppb	-40 to 85 °C	≤±0.2 ppb/day ≤±50 ppb/year ≤±300 ppb/10 years	<3 µs
ROX5242T2	52 x 42 x 14 mm 52 x 42 x 19 mm	5 to 15 MHz	≤±0.2 ppb	-40 to 85 °C	≤±0.05 ppb/day ≤±8 ppb/year ≤±40 ppb/20 years	<3 µs
ROX2522S3	25.4 x 22 x 12.1 mm	10 to 40 MHz	≤1 ppb pk-pk	-40 to 85 °C	≤±0.3 ppb/day ≤±10 ppb/month ≤±50 ppb/year	<8 µs
ROX3827T3	38.1 x 27.1 x 17 mm	5 to 40 MHz	≤1 ppb pk-pk	-40 to 85 °C	≤±0.3 ppb/day ≤±10 ppb/month ≤±50 ppb/year	<5 µs
ROX3627T3	36.5 x 27 x 19 mm 36.5 x 27 x 13.7 mm	5 to 40 MHz	≤±5 to 10 ppb	-40 to 85 °C	≤±0.3 ppb/day ≤±10 ppb/month ≤±50 ppb/year	<5 µs
ROX2525S4	25 x 25 x 15.24 mm	10 to 40 MHz	≤±5 to 10 ppb	-40 to 85 °C	≤±0.5 ppb/day ≤±15 ppb/month ≤±75 ppb/year	<25 µs
ROX2522S4	25.4 x 22 x 11.5 mm	10 to 40 MHz	±5 to 10 ppb	-40 to 85 °C	≤±0.5 ppb/day ≤±15 ppb/month ≤±75 ppb/year	<25 µs

型号	尺寸	频率范围	精度	工作温度	长期稳定性	24小时滞留
ROD2522S2H	25.4 x 22.0 x 12.1 mm	10 to 20 MHz	≤0.5 ppb pk-pk	-40 to 85 °C	≤±0.2 ppb/day ≤±10 ppb/month ≤±50 ppb/year	1.5 µs
ROD2522S2	25.4 x 22.0 x 12.1 mm	10 to 20 MHz	≤0.5 ppb pk-pk	-40 to 85°C	≤±0.2 ppb/day ≤±10 ppb/month ≤±50 ppb/year	1.5 µs
ROD3827T2	38 x 27 x 12 mm	10 to 20 MHz	≤0.5 ppb pk-pk	-40 to 85°C	≤±0.2 ppb/day ≤±10 ppb/month ≤±50 ppb/year	1.5 µs
ROD5242T1	52 x 42 x 14 mm	10 to 20 MHz	≤0.1 ppb pk-pk	-40 to 85°C	≤±0.1 ppb/day ≤±10 ppb/month ≤±50 ppb/year	≤1.5 µs

型号	尺寸	频率范围	精度	工作温度	电压	相位噪声
LNO100SAD	96 x 80 x 35 mm	80 to 125 MHz	≤±0.5 ppm	-40 to 85 °C	12 V	Typ. P/N @100 MHz -160 dBc/Hz @1 kHz -170 dBc/Hz @10 kHz -173 dBc/Hz @1 MHz
LNO100SAC	59.2 x 48.2 x 22 mm	80 to 125 MHz	≤±0.5 ppm	-40 to 85 °C	12 or 15 V	Typ. P/N @100 MHz -163 dBc/Hz @1 kHz -178 dBc/Hz @10 kHz
LNO100PTH3	25 x 25 x 13 mm	80 to 125 MHz	≤±0.5 ppm	-40 to 85 °C	12 or 15 V	Typ. P/N @100 MHz -165 dBc/Hz @1 kHz -178 dBc/Hz @10 kHz
LNO100SMD1	25 x 22 x 13 mm	80 to 125 MHz	≤±0.5 ppm	-40 to 85 °C	12 or 15 V	Typ. P/N @100 MHz -165 dBc/Hz @1 kHz -178 dBc/Hz @10 kHz

型号	尺寸	频率	精度	工作温度	长期稳定性	相位噪声
LNO320B1	95 x 76 x 23 mm	320 MHz	≤±1 ppm	0 to 50 °C	<±1 ppm/year <±6 ppm/10 years	Typ. P/N @320 MHz -152 dBc/Hz @1 kHz -174 dBc/Hz @10 kHz -180 dBc/Hz @100 kHz
LNO320D1	70 x 70 x 35 mm	320 MHz	≤±2 ppm	-40 to 80 °C	<±1 ppm/year <±6 ppm/10 years	Typ. P/N @320 MHz -172 dBc/Hz @10 kHz -178 dBc/Hz @100 kHz
LNO480D1	70 x 70 x 35 mm	480 MHz	≤±2 ppm	-35 to 71 °C	<±1 ppm/year <±6 ppm/10 years	Typ. P/N @480 MHz -145 dBc/Hz @1 kHz -180 dBc/Hz @100 kHz
LNO480B2	47.5 x 59.5 x 12.7 mm	480 MHz	≤±2 ppm	0 to 50 °C	<±1 ppm/year <±6 ppm/10 years	Typ. P/N @480 MHz -141 dBc/Hz @1 kHz -165 dBc/Hz @10 kHz -178 dBc/Hz @100 kHz
LNO500B2	47.5 x 59.5 x 12.7 mm	500 MHz	≤±2 ppm	0 to 50 °C	<±1 ppm/year <±6 ppm/10 years	Typ. P/N @500 MHz -141 dBc/Hz @1 kHz -165 dBc/Hz @10 kHz -178 dBc/Hz @100 kHz
LNO500D1	70 x 70 x 35 mm	500 MHz	≤±1 ppm	-40 to 70 °C	<±1 ppm/year <±6 ppm/10 years	Typ. P/N @500 MHz -142 dBc/Hz @1 kHz -168 dBc/Hz @10 kHz -178 dBc/Hz @100 kHz
LNO640B1	95 x 76 x 23 mm	640 MHz	≤±2 ppm	0 to 50 °C	<±1 ppm/year <±6 ppm/10 years	Typ. P/N @640 MHz -146 dBc/Hz @1 kHz -168 dBc/Hz @10 kHz -174 dBc/Hz @100 kHz
LNO640D1	70 x 70 x 35 mm	640 MHz	≤±2 ppm	-40 to 70 °C	<±1 ppm/year <±6 ppm/10 years	Typ. P/N @640 MHz -168 dBc/Hz @10 kHz -174 dBc/Hz @100 kHz
LNO800E1	25.4 x 22 x 12.7 mm	800 MHz	≤±3 ppm	0 to 50 °C	<±1 ppm/year <±6 ppm/10 years	Typ. P/N @800 MHz -137 dBc/Hz @1 kHz -160 dBc/Hz @10 kHz -167 dBc/Hz @100 kHz
LNO960B2	47.5 x 59.5 x 12.7 mm	960 MHz	≤±2 ppm	0 to 50 °C	<±1 ppm/year <±6 ppm/10 years	Typ. P/N @960 MHz -135 dBc/Hz @1 kHz -159 dBc/Hz @10 kHz -172 dBc/Hz @100 kHz
LNO1000D1	70 x 70 x 35 mm	1 GHz	≤±2 ppm	-40 to 70 °C	<±1 ppm/year <±6 ppm/10 years	Typ. P/N @1000 MHz -135 dBc/Hz @1 kHz -159 dBc/Hz @10 kHz -172 dBc/Hz @1 MHz
LNO1000E1	25.4 x 22 x 12.7 mm	1 GHz	≤±2 ppm	0 to 50 °C	<±1 ppm/year <±6 ppm/10 years	Typ. P/N @1000 MHz -128 dBc/Hz @1 kHz -156 dBc/Hz @10 kHz -168 dBc/Hz @100 kHz
LNO1000B2	47.5 x 59.5 x 12.7 mm	1 GHz	≤±2 ppm	0 to 50 °C	<±1 ppm/year <±6 ppm/10 years	Typ. P/N @1000 MHz -135 dBc/Hz @1 kHz -159 dBc/Hz @10 kHz -172 dBc/Hz @100 kHz
LNO1200B2	47.5 x 59.5 x 12.7 mm	1.2 GHz	≤±2 ppm	0 to 50 °C	<±1 ppm/year <±6 ppm/10 years	Typ. P/N @1200 MHz -128 dBc/Hz @1 kHz -154 dBc/Hz @10 kHz -172 dBc/Hz @100 kHz
LNO1200E1	25.4 x 22 x 12.7 mm	1.2 GHz	≤±2 ppm	0 to 50 °C	<±1 ppm/year <±6 ppm/10 years	Typ. P/N @1200 MHz -124 dBc/Hz @1 kHz -152 dBc/Hz @10 kHz -168 dBc/Hz @1 MHz
LNO1280B1	95 x 76 x 23 mm	1.2 GHz	≤±2 ppm	0 to 50 °C	<±1 ppm/year <±6 ppm/10 years	Typ. P/N @1280 MHz -140 dBc/Hz @1 kHz -166 dBc/Hz @1 MHz
LNO2000B1	95 x 76 x 23 mm	2 GHz	≤±2 ppm	0 to 50 °C	<±1 ppm/year <±3 ppm/10 years	Typ. P/N @2000 MHz -132 dBc/Hz @1 kHz -166 dBc/Hz @1 MHz
LNO3200B3	120 x 76 x 23 mm	3200 MHz	≤±2 ppm	0 to 50 °C	<±1 ppm/year <±3 ppm/10 years	Typ. P/N @3200 MHz -132 dBc/Hz @1 kHz -152 dBc/Hz @10 kHz -157 dBc/Hz @1 MHz
LNO4800B3	120 x 76 x 23 mm	4.8 GHz	≤±2 ppm	0 to 50 °C	<±1 ppm/year <±3 ppm/10 years	Typ. P/N @4800 MHz -118 dBc/Hz @1 kHz -144 dBc/Hz @10 kHz -157 dBc/Hz @1 MHz
LNO5000B3	120 x 76 x 23 mm	5000 MHz	≤±2 ppm	0 to 50 °C	<±1 ppm/year <±6 ppm/10 years	Typ. P/N @5000 MHz -123 dBc/Hz @1 kHz -146 dBc/Hz @10 kHz -157 dBc/Hz @1 MHz
LNO10000B3	120 x 76 x 23 mm	10 GHz	≤±2 ppm	-40 to 70 °C	<±1 ppm/year <±3 ppm/10 years	Typ. P/N @10000 MHz -115 dBc/Hz @1 kHz -140 dBc/Hz @10 kHz -151 dBc/Hz @1 MHz

型号	图片	尺寸	频率范围	工作温度	偏差	长期稳定性	相位噪声
HSO14		73 x 135 x 84 mm	5 to 10 MHz	0 to 50 °C	1 - 30s: 6 x 10-14	≤±50 ppt/day ≤±1.5 ppb/month ≤±10 ppb/year ≤±50 ppb/10 years	Max. P/N @5 MHz -150 dBc/Hz @10 Hz -157 dBc/Hz @100 Hz -160 dBc/Hz @1 kHz
HSO13		67 x 60 x 40 mm	5 to 10 MHz	0 to 50 °C	1 - 30s: 1 x 10-13	≤±50 ppt/day ≤±1.5 ppb/month ≤±10 ppb/year ≤±50 ppb/10 years	Max. P/N @5 MHz -150 dBc/Hz @10 Hz -157 dBc/Hz @100 Hz -160 dBc/Hz @1 kHz

型号	尺寸	频率范围	工作温度	偏差	长期稳定性	相位噪声
RK410	99 x 88 x 54 mm	5 to 10 MHz	0 to 60 °C -20 to 60 °C -30 to 60 °C	1 - 10s: 2 x 10-13	≤±20 ppb/year ≤±50 ppb/15 years	Max. P/N @10 MHz -122 dBc/Hz @1Hz -140 dBc/Hz @10 Hz -145 dBc/Hz @100 Hz -146 dBc/Hz @1 kHz
RK409AV	60 x 60 x 32 mm	10, 10.23, 10.24 MHz	-10 to 60 °C -25 to 65 °C -30 to 70 °C	1s: 2.5 x 10-13	≤±30 ppb/year ≤±200 ppb/15 years	Typ. P/N @10 MHz -142 dBc/Hz @10 Hz -151 dBc/Hz @100 Hz -156 dBc/Hz @10 kHz
RK409GP	50 x 55 x 30 mm	10 to 50 MHz	-10 to 60 °C -20 to 70 °C -40 to 70 °C	1s: 6 x 10-13	≤±50 ppb/year ≤±300 ppb/18 years	Typ. P/N @10 MHz -141 dBc/Hz @10 Hz -154 dBc/Hz @100 Hz -157 dBc/Hz @10 kHz
RK408	40 x 66 x 20 mm	10 to 120 MHz	-5 to 60 °C -20 to 70 °C -40 to 70 °C	1s: 5 x 10-12	≤±100 ppb/day ≤±300 ppb/18 years	Max. P/N @10 MHz -130 dBc/Hz @10 Hz -165 dBc/Hz @1 kHz -165 dBc/Hz @10 kHz
RK407	25 x 25 x 17 mm	10 to 130 MHz	-40 to 70 °C -40 to 85 °C	1s: 5 x 10-11	≤±5 ppb/day ≤±0.3 ppm/year±1 ppm/10 years	Max. P/N @45 MHz -95 dBc/Hz @10 Hz -145 dBc/Hz @1 kHz -152 dBc/Hz @10 kHz

型号	图片	尺寸	频率范围	稳定等级	工作温度	长期稳定性	相位噪声
ROX5050S		50 x 50 x 34 mm	10 to 10.23 MHz	10-8	-20 to 70 °C	≤±1 ppb/day ≤±30 ppb/year ≤±250 ppb over life	Typ. P/N @10 MHz -140 dBc/Hz @10 Hz -150 dBc/Hz @100 Hz -155 dBc/Hz @1 kHz
ROX5555S		55 x 55 x 35 mm	70 to 130 MHz	10-8	-10 to 60 °C	≤±1 ppb/day ≤±30 ppb/month ≤±100 ppb/year	Typ. P/N @100 MHz -90 dBc/Hz @10 Hz -130 dBc/Hz @1 kHz -145 dBc/Hz @10 kHz

型号	尺寸	频率范围	稳定等级	工作温度	长期稳定性	电压
RK409RBNS	60 x 60 x 32 mm	4.5 to 20 MHz	10-9	-20 to 50 °C	≤±20 ppb/year ≤±100 ppb/5 years	12 V
RK409AVNS	60 x 60 x 32 mm	10, 10.23 MHz	10-9	-10 to 60 °C	±30 ppb/year ±150 ppb/10 years	12 V
RK409NS	50 x 50 x 30 mm	10, 10.23, 10.24 MHz	10-9	-20 to 65 °C	≤±0.5 ppb/day ≤±1.5 ppb/month ≤±30 ppb/year ≤±200 ppb lifetime	12 V
RK406NS	25.4 x 25.4 x 13 mm	10 to 125 MHz	10-6	-20 to 70 °C	≤±1 ppb/day ≤±30 ppb/year ≤±100 ppb lifetime	5 V

型号	图片	尺寸	频率范围	精度	工作温度	长期稳定性	相位噪声
MRO NS Compact		216 x 108 x 116 mm	100, 200 MHz	≤±1.5 ppb	-15 to 60 °C	≤±50 ppb/2 years ≤±200 ppb/12 years	Typ. P/N @100 MHz -100 dBc/Hz @10 Hz -125 dBc/Hz @100 Hz -165 dBc/Hz @floor
MRO NewSpace		226 x 120 x 105 mm	10 to 240 MHz	≤±1 ppb	-35 to 65 °C	≤±200 ppb/12 years	Typ. P/N @100 MHz -105 dBc/Hz @10 Hz -125 dBc/Hz @100 Hz -160 dBc/Hz @floor

型号	图片	尺寸	频率范围	精度	工作温度	长期稳定性	相位噪声
MRO HR		240 x 270 x 240 mm	5 to 200 MHz	±0.1 ppb ±0.5 ppb ±5 ppb	-5 to 60 °C -20 to 70 °C -40 to 70 °C	≤±100 ppb/20 years	Typ. P/N @10 MHz -105 dBc/Hz @1 Hz -145 dBc/Hz @100 Hz -155 dBc/Hz @floor

型号	尺寸	频道	准确率	工作温度	电压	原产地
GNSS TIMING	128 x 110 x 64 mm	Up to 448	<1.2 m;(800 km altitude)	-20 to 65°C	5 to 28 V	FRA
GNSS SINGLE	130 x 122 x 24 mm	Up to 448	<1.2 m;(800 km altitude)	-30 to 70 °C	3.3 to 32 V	FRA
GNSS DUAL	130 x 122 x 24 mm	Up to 448	<1.2 m;(800 km altitude)	-30 to 70 °C	3.3 to 32 V	FRA
GNSS DB	55 x 41 x 16 mm	Up to 448	<1.2 m;(800 km altitude)	-30 to 70 °C	3.3 V	FRA

型号	图片	尺寸	频率范围	频率稳定度	工作温度	电压	相位噪声
PLO NS LN		50 x 50 x 16 mm	10 to 120 MHz	N/A	-25 to 60°C	12 V	Typ. P/N @10 MHz -120 dBc/Hz @100 Hz -150 dBc/Hz @10 kHz -155 dBc/Hz @1 MHz

型号	尺寸	工作温度	电压	压缩器通道	高bxt压缩增益和冲击
CIF07	175x152x27.1mm	-25 to 60 °C	11, 26 V	Two expander IF channels with IF analog I/Os	T = 1000 µs (B <7 MHz)
CIF06	175x152x27.1mm	-25 to 60 °C	11, 26 V	1 expander channel and 1 compressor channel with IF analog I/Os	T = 950 µs (B <3 MHz); T = 170 µs (B <7 MHz); T = 17 µs (B <20 MHz)
CIF0405	175x152x27.1mm	-25 to 60 °C	11, 26 V	CI F04: 1 compressor channel; CI F05: 2 independent compressor channels	T = 950 µs (B <3 MHz); T = 170 µs (B <7 MHz); T = 17 µs (B <20 MHz)
CIE03	120x75x10mm	-40 to 70 °C	5.5, 13.2 V	2 concurrent channels: Expander or compressor for each channel	T = 950 µs (B <3 MHz); T = 170 µs (B <7 MHz); T = 17 µs (B <20 MHz)
